Linkage
Tools
With Viroc, you can use third-party accessory units you already own. The three-point linkage offers a lifting capacity of 1,000 kg / 2,200 lbs at the hooks, providing optimal multifunctionality.
Drag to change the 360 view angle
Drag to view
Compatible with third-party accessory units
Lifting capacity at the hooks: 1,000 kg / 2,200 lbs
Maximum functionality
Technical data
Three-point linkage
Cat. 2S ISO 730-1
Minimum lifting capacity at the attachment points
1,000 kg / 2,200 lbs
Recommended max. weight of the accessory
ca. 700 kg / 1,540 lbs
Optional
Hydraulic top link
Valve block for 5 free cylinder movements with a maximum of 180 bar & 13.5 l/min / 3.5 gal/min
Mounting frame with three-point linkage
Cat. 2S Ø 22 / 0.87 in
Cat. 2S Ø 28 / 1.10 in
Fendt Ø 22 / 0.87 in
